| Model Number | DALICU04-SL-FM FW56 |
| Full Product Name | DALI Controlgear |
| Line Voltage | 100 ~ 277Vac |
| Model Number | DALICU04-SL-FM FW56 |
Full Product Name | DALI Controlgear |
| Line Voltage | 100 ~ 277Vac |
Line Curren | 0.1A Max. (AC output power is not included) |
| Line Frequency | 50 / 60Hz |
Min. Mains Voltage Operational | 90Vac |
| Min. Mains Voltage Operational | 300Vac |
Inrush Current | Cold Start ≤ 60A (twidth = 50us measured at 10% Ipeak) @ 277Vac, Per NEMA 410 |
| AC Output Current | 8A / 120Vac, 6A / 230Vac, 5A / 277Vac |
AC Output Inrush Current | 180A, 10ms (max.) |
| Analog 0-10V Interface Max. Current | Sourcing / Sinking ≤ 25mA |
DALI Output Voltage Typ. | 15Vdc |
| DALI Guaranteed Output Current | 55mA |
Protections | Short circuit protection of DA+ / DA- |
Protection Rating | IP24 |
Ambient Temp Range | -20℃ to +70℃ |
Dimensions | 160×30×25mm |
